MPTP-TU100S-3.0D
Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to the real product. This manual is only for operation instructions. Please contact the local distributor for maintenance assistance. The functions described in this version were updated as of November 3, 2023. In the constant effort to improve the product, we reserve the right to make changes to functions or parameter changes without notice or obligation. Please refer to the dealers for the latest details.
Features
- USB3.2 Gen1 data transfer rate up to 5Gbps
- Support extending the USB signal up to 100m
- Support RS232 pass-through/control/upgrade
- Support USB device power management
- Bi-directional 24V PoC power supply
Powered by Froala Editor
Specification
| DevicesConnector | (3)Type-AUSB(1)Type-CUSB |
| DevicesPower | Devicesshare3Acurrent limit; Singleportpowersupplymaximumlimit1.7A. |
| USBVersion | USB3.2Gen1 |
| Control | (1)3-pinterminalblock(1)2-pinDIPswitch |
| Transmitdistance | Upto100mwithCAT6Acable (Thecurrentversiononlyreachesthe70mextension) |
| DataRate | 5Gbps |
| OperationTemperature | -10℃~+55℃ |
| StorageTemperature | -25℃~+70℃ |
| RelativeHumility | 10%~90% |
| ExternalPowerSupply | DC24V1.5A |
