MP-HM-VCC-4K
The HDMI video capture can capture HDMI video and HDMI audio with MIC audio mix. It can transmit an audio signal to a computer and a smartphone to preview and store. Suitable for game live meetings, the HD recording supports the RGB format.
Features
- Input: 4k HDMI 2.0 input, microphone input
- Output: 4k HDMI 2.0 loop out, Type-C (5Gbps) output, audio output
- Automatic detection of the input signals, resolution up to 4K@60Hz
- Support video format: MJPEG/YUY2/NV12/I420,etc.
- Uncompressed video and audio acquisition, meet the UVC and UAC standards
- USB Type-C power supply, plug and play, no drive
- Compatible with Windows, MacOS
- Compatible with OBS, Potplayer, VLC, Vmix, etc
Powered by Froala Editor
Specifications
| Input resolution | maximum 4k@60Hz 4:4:4 |
| Output resolution | maximum 4k@60Hz |
| Video output mode | MJPEG/YUY2/NV12/I420 |
| Max bandwidth | 600MHz |
| Max baud rate | 18Gbps |
| Support audio format | meet the UVC and UAC standards |
| Max working current | 0.7A/5VDC |
| Operating temperature range | (-10 to +55℃) |
| Dimension | 100x63x16 (mm) |
| Weight | 126g |
