MP-LITE COLLAB
MP-LITE COLLAB is a cost-down version of MP-PRO COLLAB. It eliminates some redundant hardware interfaces, including dual HDMI outputs and a secondary USB-B host channel, focusing specifically on essential single-screen wireless BYOM applications. It also further optimizes the configuration, such as adding an analog audio input as a microphone, and capturing HDMI in as a camera. MP-LITE COLLAB is the optimal balance between advanced functionality and cost consideration in modern conference rooms. It effectively addresses most of the standard conference room needs for seamless BYOD content sharing and video collaboration.
- Wireless content sharing up to 4K resolution, HDMI 2.0 output
- Support native wireless mirroring protocols like AirPlay, Miracast, Chromecast
- Support plug-n-play HDMI/Type-C dongles for wireless presentation
- Support Android, MAC, and Windows apps for wireless presentation
Support wireless touch back on interactive whiteboard/touch screen
Powered by Froala Editor
| HDMI output | 1x HDMI 19-pin female connector |
| HDMI Output Resolution | 3840x2160@60Hz,3840x2160@30Hz, 1920x1080@60Hz, 1280x720@60Hz |
| HDMI Format Compliance | HDMI1.4/HDMI2.0 |
| Video Capacity: | 1080P @ ≤60Hz for Airplay, Miracast, Chromecast |
| HDCP | HDCP1.4/HDCP2.2 |
| HDMI Input | 1x HDMI 19-pin female connector |
| HDMI Input Format Compliance | HDCP1.4 |
| HDMI Input Resolution | 3840x2160@30Hz,31920x1080@60Hz, 1280x720@60Hz |
| Analog Audio Output | 1x 3.5mm PC audio female jack |
| Analog Audio Input | 1x 3.5mm PC audio female jack |
