MPTP-T100SS-H2
MPTP-T100SS-H2 is an HDMI 2.0 HDBaseT Extender set consist of transmitter and receiver. It extends 1080p HDMI signal via CAT5e/6a cable at 100m/PoC , and enables IR and RS232 pass through to control local source device from remote or far end display It also features 4 Ethernet ports for network extension.
Supports HDMI 2.0 and HDCP 2.2 and is backward compatible to the previous version.
Maximum transmission distance is up to 70m for 4Kx2K, and 100m for 1080p.
Supports bi directional IR and RS232 pass through for long distance control.
Supports bi directional PoC for simplified wiring.
Supports HDR.
Features DIP switcher for choosing RS232 mode: Control or Update.
Powered by Froala Editor
| Transmitter | Receiver | |
| Input | HDMI IN | HDBT IN |
| Output | HDBT OUT | HDMI OUT |
| Control Ports | IR IN, IR OUT , RS232 | IR IN, IR OUT , RS232 |
| Ethernet Ports | (2) RJ45 connectors | (2) RJ45 connectors |
| General | ||
| Transmission Mode Distance | HDBaseT 1080 p ≤ 100m; 4K×2K ≤ 70m | |
| Ethernet Transmission Speed | Adaptive 10M/100M (max), full duplex or half duplex | |
| Resolution | Up to 4K×2K@60Hz 4:4:4 | |
| Bandwidth | 18Gbps | |
| HDMI Standard | HDMI 2.0 and HDCP 2.2 | |
| Power Consumption | 17W (max) | |
| Temperature | -10℃~ 50℃ | |
| Humidity | 0% ~ 90% | |
| Power Supply | Input: 100VAC~240VAC, 50/60Hz; Output: 24VDC 1.25A | |
| Dimension (W*H*D) | 152mmx16.2mmx104mm | 152mmx16.2mmx104mm |
| Net Weight (g) | 240g | 240g |
