4K HDMI MP-7RX
Read this user manual carefully before using the product. The pictures shown in this manual are for reference purposes only. Different models and specifications are subject to the real product. This manual is only for operation instructions. Don't hesitate to contact the local distributor for maintenance assistance. The functions described in this version were updated till July 25th, 2025. In the constant effort to improve the product, we reserve the right to make changes to functions or parameters without notice or obligation. Please refer to the dealers for the latest details.
Features
- Support Miracast and AirPlay screencast protocols.
- Support up to 4K@30Hz Ultra High definition.
- Wireless transmission up to 15 meters.
- Low latency, with less than 50ms delay within 6 meters.
- Image rotation with 90° and 270° options available.
- 5G transmission, anti-interference, no jamming.
- Plug and play.
- Configure via web-GUI.
- Compact design and travel-friendly.
Powered by Froala Editor
| Interface | HDMI1.4 |
| Bandwidth | 10.8Gbps |
| Resolution | 3840x2160@30Hz,1920x1080@60Hz,1280x720@60Hz, 720x480@60Hz. |
| Scaling | Up to 15 meters (with less than 50ms delay within 6 meters) |
| Transmission | Miracast, AirPlay |
| Protocol | Android, IOS, macOS, Windows |
| System | DC5V/1A |
| Power Supply | 0°C ~ +50°C |
| Operation Temperature | 10%-90% |
| Relative Humidity | 65mmx200mmx15.8mm |
