MP-SUH-41MV
MP-SUH-41MV is a 4K Multiview switcher. It is seamless video scaler designed to enable a true 4K display.It features four HDMI inputs and one HDMI output which allows you to display four video sources on one display. It also provides a line input , 1 mix input, 1 SPDIF output and 1 analog output for audio processing. Control is quick and comprehensive, whether you are using the front panel, the remote control, RS232 commands, or the fully featured web GUI.
- 4 x HDMI inputs, 1 x HDMI output.
- Supports 4K@30Hz 4:4:4, HDCP 2.2.
- Seamless switch between 4 input ports.
- Auto Scaler in each source input.
- Supports audio embedding and mixing.
- Supports audio de embedding.
- Auto switching at single window.
- Cycles through the windows from A to D by swap button.
- Base on FPGA Technology, layout and size of the windows can be customized.
- Resizes the windows in 3 different sizes.
- 16 pre defined layouts for multi view.
- Multiple control methods , including an assignable front panel, IR remote, web GUI and RS232 port.
Powered by Froala Editor
| Video | |
| Input | (4) HDMI IN (1~4) |
| Input Connector | (4) Type-A female HDMI |
| HDMI Input Resolution | Up to 4K@30Hz 4:4:4 |
| Output | (1) HDMI |
| Output Connector | (1) Type-A female HDMI |
| HDMI Output Resolution | Up to 4K@30Hz RGB |
| HDMI Standard | HDMI 1.4 |
| HDCP Version | Up to HDCP 2.2 |
| Audio IN | |
| Audio In | (1) LINE IN, (1) MIX IN |
| Audio In Connector | (2) 3-pin terminal connectors |
| Frequency Response | 20Hz to 20KHz, ±3dB |
| Max Input Level | 2.0 Vrms ±0.5dB 2V=16dB headroom above -10 dBV (316 mV) nominal consumer line level signal. |
| L-R level deviation | < 0.3 dB, 1 kHz sine at 0 dBFS level (or max level before clipping) |
| Input Impedance | > 10kohm |
| Audio Format | PCM 2CH |
| SPDIF OUT | |
| SPDIF Out | (1) SPDIF |
| Audio Out Connector | (1) Toslink |
| Max Output level | ±0.05dBFS |
| Frequency Response | 20 Hz to 20 kHz, ±1dB |
| THD+N | < 0.05%, 20 Hz – 20 kHz bandwidth, 1 kHz sine at 0 dBFS level (or max level) |
| Noise | -90dB |
| Audio Format | PCM 2CH |
| Audio Out | |
| Audio Out | (1) AUDIO |
| Audio Out Connector | (1) 3.5mm mini jack |
| Frequency Response | 20 Hz to 20 kHz, ±1dB |
| Max Output Level | 2.0 Vrms ± 0.5 dB. 2 V = 16 dB headroom above -10 dBV (316 mV) nominal consumer line level signal |
| THD+N | < 0.05%, 20 Hz – 20 kHz bandwidth, 1 kHz sine at 0 dBFS level (or max level) |
| Signal-to-Noise Ratio | > 80dB, 20Hz-20 kHz bandwidth |
| Crosstalk Isolation | < -80 dB, 10 kHz sine at 0 dBFS level (or max level before clipping) |
| L-R Level Deviation | < 0.05 dB, 1 kHz sine at 0 dBFS level (or max level before clipping) |
| Output Load Capability | 1k ohm and higher (supports 10x paralleled 10k ohm loads) |
| Noise | -80dB |
| Control | |
| Control port | (1)RS232, (1)TCP/IP |
| Control Connector | (1) 3-pin terminal connector, (1) RJ45 |
| General | |
| Operation Temperature | -5°C ~ +55°C |
| Storage Temperature | -25 ~ +70°C |
| Relative Humidity | 10% ~ 90% |
| External Power Supply | Input: AC 100~240V, 50/60Hz; Output: 24V DC 1.25A |
| Power Consumption | 13w(Max) |
| Dimension(W*H*D) | 285mm x 27mm x 172.5mm |
| Net Weight | 1.24kg |
