MPTP-TUH43T
Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to the real product. This manual is only for operation instructions. Please contact the local distributor for maintenance assistance. The functions described in this version were updated as of December 8 th 2025. In the constant effort to improve the product, we reserve the right to make functions or parameters without notice or obligation. The dealers for the latest details.v
Features
- 18Gbps high bandwidth, HDMI V2.0.
- HDMI video resolution up to 4K@60Hz 4:4:4, HDR10, Dolby Vision
- Supports to transmit up to 40m at 4K@60Hz and 70m at 4K@30Hz
- Two-way IR and RS232 pass-through
- Supports two-way 24V PoC.
- Supports audio pass-through
- Provides an HDMI loop-out on the transmitter.
Powered by Froala Editor
Specification
| Input | 1x VIDEO IN | |
| Input Connector | 1x Type-A female HDMI | |
| Input Resolution | Up to 4K@60Hz 4:4:4 | |
| Output | 1x HDBT OUT, 1x LOOPOUT | |
| Output Connector | 1x RJ45, 1x Type-A female HDMI | |
| Output Resolution | Up to 4K@60Hz 4:4:4 | |
| Input | 1x L/R IN | |
| Input Connector | 1x 3.5mm jack | |
| Audio Format | 3.5mm Audio: PCM 2CH | |
| Frequency Response | 20Hz ~ 20KHz, ±3dB | |
| Max Output Level | 2.0Vrms ± 0.5dB. 2V = 16dB headroom above -10dBV(316mV) nominal consumer line level signal | |
| THD+N | < 0.05% (-80dB), 20Hz~20KHz bandwidth, 1kHz sine at 0dBFSlevel (ormax level) | |
| SNR | > 85dB, 20Hz-20kHz bandwidth | |
| Crosstalk Isolation | > 70dB, 10kHz sine at 0dBFS level (or max level before clipping) | |
| L-R Level Deviation | < 0.3dB, 1kHz sine at 0dBFS level (or max level before clipping) | |
| Frequency Response Deviation | < ± 0.5dB, 20Hz – 20kHz | |
| Output Load Capability | 1KΩ and higher (Supports 10x paralleled 10KΩ loads) | |
|
||
|
||
|
