MP-SC-41BYOD
MP-SC-41BYOD is a 18G 4x1 Presentation Switcher. It is designed with one wireless Miracast /Airplay input, two HDMI inputs, one USB-C input and one HDMI output. It supports HDMI 2.0, 4Kx2K@60Hz 4:4:4, HDR 10, Dolby Vision, and HDCP 2.2. In addition, there is smart built in EDID setting can be selected by the 4-pin DIP switch on the front panel. It supports HDMI audio de-embedding . It also supports USB device extension by providing two type-B USB ports for host connection, and two type-A USB ports for USB devices such as camera, microphone, keyboard etc. It features multiple methods of control. When at the AUTO mode, the switcher will automatically switch to the first detected source device.
- 18G 4x1 presentation switcher with soft codec & wireless BYOD.
- Supports HDMI 2.0 b , 4Kx2K@60Hz 4:4:4, HDR 10, Dolby Vision and HDCP 2.2
- Wireless BYOD (Bring Your Own Device) capability via AirPlay and Miracast.
- Provide up to 60w charging, USB data (USB 3. 0 /2.0) and 4K video transmission on USB-C port.
- HDMI output audio can be de embedded out via balanced analog audio port.
- Two type-B USB ports for host connection, and two type-A USB ports for USB devices like webcam, mic and keyboard.
- Supports video source auto switching.
- Smart EDID management.
- Front panel buttons trigger both CEC and RS232 commands for display control.
Powered by Froala Editor
| Video | |
| Input | (1) AirPlay/Miracast, (2) HDMI, (1) USB-C |
| Input Connector | (1) External antenna connector, (2) Type-A female HDMI, (1) Type-C USB 3.0 |
| AirPlay/Miracast Input Resolution | Up to 4K@30Hz 4:4:4 |
| HDMI Input Resolution | Up to 4Kx2K@60Hz 4:4:4 HDR10, Dolby Vision |
| USB-C Input Resolution | Up to 4K@30Hz 4:4:4 |
| Output | (1) HDMI |
| Output Connector | (1) Type-A female HDMI |
| HDMI Output Resolution | Up to 4Kx2K@60Hz 4:4:4 HDR10, Dolby Vision |
| HDMI Standard | Up to HDMI 2.0b |
| HDCP Version | Up to HDCP 2.2 |
| Audio | |
| HDMI Embedded Audio Format | Supports Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, Dolby Digital, DTS-X, DTS-HD Master Audio, DTS 5.1, 2 - 8Ch PCM 32-192kHz 16-24 bits; 2-8Ch PCM 32-192kHz 16-24 bits |
| Balanced Analog Audio Output | (1) AUDIO OUT |
| Balanced Analog Audio Output Connector | (1) 5-pin terminal block |
| Frequency Response | 20Hz–20KHz, ±3dB |
| Max Output Level | 2.0Vrms ± 0.5dB |
| THD+N | < 0.05%, 20Hz – 20KHz bandwidth, 1KHz sine at 0dBFS level (or max level) |
| SNR | >80dB, 20Hz - 20KHz bandwidth |
| Crosstalk Isolation | <-80dB, 10KHz sine at 0dBFS level (or max level before clipping) |
| L-R Level Deviation | <0.05dB, 1KHz sine at 0dBFS level (or max level before clipping) |
| Output Load Capability | 1KΩ and higher (Supports 10x paralleled 10KΩ loads) |
| Noise Level | -80dB |
| Control | |
| Control port | (1) 4-pin DIP switch, (1) FW, (2) HOST (PC1&PC2), (2) DEVICES, (1) RS232 |
| Control Connector | (1) Micro-USB, (2) Type B USB 3.0 (2) Type A USB 3.0, (1) 3 pin terminal block |
| Network Connectivity | |
| WLAN Standards | IEEE 802.11ac |
| Band | 2.4 and 5GHz |
| Max. Wireless Coverage | ≤5m, environment dependent, reduce disturbance to increase transmission distance up to 10m |
| Max. Output Resolution | 4K/30Hz |
| Version | iOS 7 or above, MacOS, Android 4.0 or above,Windows8.1 or above. |
| General | |
| Operation Temperature | -5℃ ~ +55℃ |
| Storage Temperature | -25℃ ~ +70℃ |
| Relative Humidity | 10% ~ 90% |
| External Power Supply | Input: AC 100~240V, 50/60Hz; Output: 24V DC 5A. |
| Power Consumption | 85w (Max) |
| USB-C Power Charging | 60w (Max) |
| Dimension (W*H*D) | 238mm x 24.5mm x 135mm |
| Net Weight | 825g |
