MP-A3B
MP-A3B is a 40W Power Amplifier (Class-D) with output alternatively at 70V or 100V. It has 2 stereo inputs (1x3.5mm jack for line in, 2xRCA for L&R), 1 digital input & 1 balanced MIC. It is integrated with powerful functions, including ducking function, EQ control, MIC mixer etc, and MIC input supports 3 levels with condenser MIC, dynamic MIC & line audio input. As for power amplifier we have normally voltages at 70V and 100V for different countries, but MP-A3B is designed to integrate with both voltages to meet different requirements.
- Mono audio output at 40Watt.
- Switchable between 70V and 100V.
- Ducking function.
- 16 ID codes for controlling between different MP-A3B amplifiers.
- 3-level MIC input, supports condenser microphone, dynamic microphone and wireless microphone.
- MIC port can support balance/unbalance signal, suppress the external noise effectively.
- Two stereo audio inputs and one digital audio input, switchable by button, IR remote & RS232.
- Volume/Bass/Treble controllable by buttons, IR remote & RS232.
- Fast switching speed for good performance.
- Convection cooler, fan is not needed.
- LED indicator, for power and working status.
- Antistatic case design to provide good protection for long-term and stable performance.
Powered by Froala Editor
| Audio Input | Audio Output | ||
| Input | (2) stereo audio (1) MIC (1) Digital fiber audio | Output | (1) mono amplifier |
| Input Connector | (2) RCA, (1) 3.5mm jack (1) 3-pole 3.81mm captive screw connector (1) SPF fiber connector | Output Connector | (1) 3-pole 3.81mm captive screw connector |
| Input Impedance | >10KΩ | Output Type | Constant voltage 70V or 100V |
| Audio General | |||
| Frequency Response | 120Hz ~ 20KHz | CMRR | >70dB@20Hz~20KHz |
| SNR | 80dB (Max) | Bandwidth | 120Hz ~ 20KHz |
| Rated Power Output | 40Watt @8Ohms | THD + Noise | 1%@1KHz, 0.3%@20KHz at nominal level |
| Voltage Gain | 26dB | ||
| Control Function | |||
| RS232 Control | (1) 3-pole 3.81mm captive screw connector | Front Panel Control | Buttons |
| ID Code Control | 16 ID codes for control | ||
| Optional | IR remote & TCP/IP controlled by PTNET(PTN's programmable interface) | ||
| General | |||
| Temperature | -10 ~ +40℃ | Humidity | 10% ~ 90% |
| Power Supply | DC 24V power adapter | Standby Power Consumption | 5W |
| Case Dimension | W130 x H44 x D144mm (1U high) | Product Weight | 0.86Kg |
