MPTP-TUH-100KVM
MPTP-TUH-100KVM is HDBaseT 2.0 KVM Extender Set is a 4K HDMI Extender set developed with the latest HDBaseT™ 2.0 technology to extend uncompressed HDMI video, audio, USB 2.0, control signals and PoC over a single CAT5e/6 cable. The unidirectional PoC compliant extender comes with only one power supply, which means that the Receiver can be powered via Transmitter to save installers time and added cost to installing a power outlet. Ideally designed for smart displays and KVM solutions fitting digital signage markets.
- Compatible with HDMI 1.4 and is backwards compatible with all previous HDMI standards (e.g. HDMI d elivers high resolution AV signal 1080p 3D, 4K @60Hz
- Support HDBT 2.0 , transmit 1080p 4K signal up to 100m over single CAT6 cable
- EDID Pass Thru
- HDCP 2.2 compliant
- Front panel status LED s for power, HDBT link & HDCP
- USB & RS232 control
- Unidirectional PoC
Powered by Froala Editor
| Transmitter | |
| Input | 1 x HDMI |
| Input Connector | 1 x 19 pin type-A male HDMI |
| Output | 1 x HDBT, 1 x USBOUT |
| Output Connector | 1 x RJ45, 1 x Type-B USB |
| Control | 1 x RS232 |
| Control Connector | 1 x 3-pin pluggable terminal block |
| Receiver | |
| Input | 1 x HDBT, 1 x USB IN |
| Input Connector | 1 x RJ45, 1 x Type-A USB |
| Output | 1 x HDMI |
| Output Connector | 1 x 19 pin Type-A male HDMI |
| Control | 1 x RS232 |
| Control Connector | 1 x 3-pin pluggable terminal block |
| General | |
| HDMI Audio Format | Supports PCM, Do l by Digital , DTS, DTS HD |
| HDMI Standard | 1.4 |
| HDCP | 2.2 |
| Transmission Distance | 1080p/4K @60Hz ≤100m ( |
| Video Resolution | Up to 4K@60Hz 4:2:0 |
| Bandwidth | 10.2Gbps |
| EDID Management | EDID Pass-Thru |
| Operation Temperature | -5 ~ +55℃ |
| Storage Temperature | -25 ~ +70℃ |
| Relative Humidity | 10% ~ 90% |
| External Power Supply | Input:100V 240V AC ; Output: DC 12V 2A |
| Power Consumption | 18W(max) |
| Dimension (W*H*D) | 4.5”x 0.86” x 3.74”/116 x 22 x 95 mm |
| Net weight | TX:197g; RX:198g |
