MP-UCUH-KVM
MP-UCUH-KVM is a USB-C to HDMI converter. It is designed to convert 4K@60Hz 4:4:4(max) USB-C video input to 4K@60Hz 4:4:4(max) HDMI video output. For the USB-C, it also supports USB 3.1 Gen2 data transfer and 60W fast-charging. In addition, the converter includes three USB 3.1 ports and one Ethernet Gigabit LAN port. It also supports plug and play, no software drivers required.
- Supports HDMI 2.0, 4K@60Hz 4:4:4, HDCP 2.3.
- USB-C input supports 60W USB Power Delivery.
- Supports USB3.1 Gen2 data transfer via USB-C.
- 3 USB 3.1 KVM for camera, keyboard and mouse.
- Ethernet Gigabit LAN
- Plug and Play.
Powered by Froala Editor
| Video Input | |
| Input | 1 x USB |
| Input Connector | 1 x USB-C |
| Input Resolution | Up to 4K@60Hz 4:4:4 |
| USB Standard | USB3.1 Gen2 |
| Video Output | |
| Output | 1 x HDMI |
| Output Connector | 1 x Female type-A HDMI |
| HDMI Output Resolution | Up to 4K@60Hz 4:4:4 |
| HDMI Standard | 2.0 |
| HDCP Version | 2.3 backwards compatible |
| USB | |
| Connector | 3 x USB-A, 1 x USB-C |
| USB Standard | 3 x USB-A: USB 3.1 Gen 1, 5V1A External Power Supply 1 x USB-C: USB 3.1 Gen 2, 60W External Charging |
| Ethernet | |
| Standard | 10/100/1000Base-T |
| General | |
| Bandwidth | 18Gbps |
| Operation Temperature | -10 ~ +55 |
| Storage Temperature | -25 ~ +70 |
| Relative Humility | 10% - 90% |
| Power Supply | DC24V5A |
| Power Consumption | 68W(Max) |
| Dimension (W*H*D) | 145mm x 80mm x 22mm |
| Net Weight | 270g |
