MP-HD-88AE-H2 KIT
The MP-HD-88AE-H2 KIT is a professional 8x8 HDMI V2.0 Matrix Switcher with audio breakout. It includes 8 HDMI inputs, 2 HDMI outputs, and 6 CATx extension outputs with an HDMI loop out. The HDMI signal is extended up to 70m over a single CATx cable. All the HDMI outputs support the down-scaling function. It also features SPDIF and analog audio outputs for audio breakout. The matrix switcher features comprehensive EDID management and advanced HDCP handling to ensure maximum functionality with a wide range of video sources. The matrix switcher not only supports bi-directional IR, RS232 control, but also TCP/IP control with Web GUI.
Features
- 8x8 HDMI V2.0 Matrix Switcher.
- Supports 4K@60 4:4:4, HDR, HDCP2.2.
- 4K/ 1080p HDMI signal extension up to 70m.
- Audio out can be de-embedded from any outputs.
- HDMI outputs support 4K to 1080p down-scaling.
- Controllable by front panel, IR, RS232, and TCP/IP.
- CATx outputs support 12V PoC power for receivers.
- Supports bi-directional IR pass-through.
Powered by Froala Editor
Specification
| VideoInput | (8)HDMI |
| InputConnector | (8) Type-A female HDMI |
| HDMI Input Resolution | Upto4K@60Hz4:4:4,HDR |
| VideoOutput | (6)CATx,(3)HDMI |
| OutputConnector | (6)RJ45,(3)Type-AfemaleHDMI |
| HDMIOutputResolution | Upto4K@60Hz4:4:4,HDR10 |
| CATxOutputdistance | Upto70m |
| HDCPVersion | Upto2.2 |
| HDMIAudioSignal | LPCM7.1audio,DolbyAtmos®,Dolby®TrueHD,DolbyDigital® Plus,DTS:X™,andDTS-HD®MasterAudio™pass-through. |
| Output | (1)DigitalSPDIFaudio,(1)Analogstereoaudio |
