MP-SC-31T CODEC

3x1 18G presentation switcher with HDBaseT output
18Gbps high bandwidth, HDMI 2.0, HDCP2.2
HDMI and USB-C video resolution up to 4K60Hz 4:4:4, HDR10, Dolby Vision
Supports to transmit up to 40m at 4K60Hz or 70m at 4K30Hz
Controlled by button on the front panel, GUI (via TCP/IP) and RS232
Supports audio volume adjust for both TX and RX
Supports two-way IR and 24V PoC
Provides HDMI loop out

The MP-SC-31T Codec is a 3×1 18G KVM switcher extender kit. It has one USB-C, two HDMI with one USB-B host, one HDMI loopout, and an HDBaseT output allow video signal to be transmitted up to 40m at 4K60Hz and 70m at 4K30Hz over a single CAT6A cable.

1 x MP-SC-31T Codec Tx	1 x MP-SC-31T Codec Rx
4 x Mounting Ears with 4 Screws	8 x Rubber Feet
2 x 5-pin Terminal Block	1 x Power Adapter (DC 24V/6.5A)
2 x 2*3pin Terminal Block	1 x 3-pin Terminal Block
Input	1 x USB-C, 2 x HDMI, 1x USB-B
Input Connector	1 x USB Type C, 2 x Type-A female HDMI, 1 x USB Type-B
Input Resolution	Support up to 4K60Hz 4:4:4
Output	1 x HDBaseT, 1 x LOOPOUT
Output Connector	1 x RJ45, 1 x Type-A female HDMI
Output Resolution	Up to 4K60Hz 4:4:4
