MP-EXT-2

Input supports 4K60Hz 4:4:4
Output supports HDMI 2.0, 4K60Hz 4:4:4
HDCP 2.3/2.2/1.x support
USB-C input supports 100W USB Power Charging
3x USB 3.2 Gen1 (5Gbps) device ports for USB peripherals such as USB cameras, keyboard, and mouse
Each USB device port can deliver up to 5V1A (5W) power
Supports auto-switching USB devices downstream

MP-EXT-2 is the USB-C to HDMI converter. This converter is designed to convert 4K60Hz 4:4:4(max) DisplayPort alt mode signal over USB-C video input to 4K60Hz 4:4:4(max) HDMI 2.0 video output. The USB-C input interface also supports USB 3.2 Gen1 data transfer, Gigabit LAN, and 100W fast-charging power delivery

Input Connector	(1) USB-C
Input Resolution	Up to 4K60Hz 4:4:4
Output Connector	(1) Female type-A HDMI
HDMI Output Resolution	Up to 4K60Hz 4:4:4 (18Gbps)
HDMI Standard	2.0b
HDCP Version	2.3/2.2/1.4 compliant
USB Standard	(3) USB-A: USB 3.2 Gen 1, 5V1A External Power Supply (1) USB-C: USB 3.2 Gen 1, Display Port Alt mode, 100W PD
Operation Temperature	-5 ~ +55℃
Storage Temperature	-25 ~ +70℃
