MPTP-TU100S-3
Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to the real product. This manual is only for operation instructions. Don't hesitate to get in touch with the local distributor for maintenance assistance. The functions described in this version were updated as of November 3, 2023. In the constant effort to improve the product, we reserve the right to make changes to functions or parameters without notice or obligation. Please refer to the dealers for the latest details.
Features
- 2x1USB3.2Gen1switcher
- Support extending the USB signal up to 100m
- Support RS232 passthrough/control/upgrade
- Auto/manual switching mode
- Bi-directional 24V PoC power supply
Powered by Froala Editor
| HostConnector | (1)Type-BUSB(1)Type-CUSB |
| DevicesConnector | (2)Type-AUSB |
| DevicesPower | 5V500mAtotal |
| USBVersion | USB3.2Gen1 |
| Control | (1)Button,(1)RS232,(1)DIPswitch |
| ControlConnector | (1)WhiteButton,(1)3-pinterminalblock,(1)2-pinDIPswitch |
| Transmitdistance | Upto100mwithCAT6Acable (Thecurrentversiononlyreachesthe70mextension) |
| DataRate | 5Gbps |
| OperationTemperature | -10℃~+55℃ |
| StorageTemperature | -25℃~+70℃ |
